Ecotric Dolphin Portable & Foldable Fat Tire Electric Bike UL Certified

Like a Dolphin, the Ecotric Dolphin Portable and Folding Fat Tire Electric Bike UL Certified is chubby and cute but flexible. It has the ability to take on many tasks you would not expect from a portable & folding bike, such as hauls from the grocery store, challenging terrain, and rough roads, all without breaking a sweat. This is a portable e-bike that you can ride for a long time on any road.

FEATURES

• A UL-Certified e-bike which means it has undergone a thorough safety review
• Rear Hub 500W Brushless Motor
• High-Performing 36V 12AH Lithium-Ion Battery
• High-Quality 20" x 4" Fat Tire
• Portable & Foldable - Easy to carry & transport
• SHIMANO 7 Speed Derailleur
• 2 Color Options, Matte Black & White

UL has been around for 125 years, ensuring electrical products' safety and accountability in everyday American life. Being UL certified illustrates a business’ dedication to consumer safety and the quality of its products. Another important caveat of UL certification is for insurance purposes and customer security. It’s a true indication of an item’s safety and longevity.

ALUMINUM ALLOY FRAME

• 20" ALLOY
• Head tube 50 x 50 x 120L
• The pipe heterotypic 27.4 x 2.2 T x 420L
• Reaming 27.4
• Equipped with rear motor
• Standard disc brake seat

500W GEAR MOTOR

• 500 Watt brushless geared motor
• Tire: 20" x 4.0" Anti-skidding,adapt to snow, sand and other complex topography
• Inner Tube: 20 × 4.0/4.9
• Valve Stem: standard American size
• Attached: valve cap

36V/12.5AH REMOVABLE LITHIUM BATTERY

• Removable battery so you can bring the battery to your home or office to recharge
• Travel range 18-23 miles in pure electric mode and 45-48 miles in pedal mode
• Charging time is approximately 6-8 hours
• Battery life up to 400-600 cycles
• Battery lock and power lock function

DISC BRAKE

• Outage braking system and Mechanical braking system, work along both lines, provide security for your trip.
• 7 Speed system
• Come with pedal assist and walk-assist model

Equipped with comfortable but compact 20" x 4" TIRES, the Dolphin can be conveniently folded to store and transport the bike more easily.

FOLDABLE & PORTABLE

✔ Put it in the trunk
✔ Take it to the elevator
✔ Take it to the subway

MEASUREMENT

SPECIFICATIONS

TECHNICAL DETAILS

MOTOR	500W Brushless Rear Hub
BATTERY	36V 12Ah Lithium-Ion
CHARGE TIME	5-8 Hours
DRIVE MODE	Pedal Assist On-Demand Throttle
BATTERY LIFE	400-600 Cycles
RANGE	20+ Miles
DISPLAY	Ecotric LED
READOUTS	Battery Charge Level (4 Bars), 3 PAS Levels, Cruise Control Support

BICYCLE COMPONENTS

TOTAL WEIGHT W/ BATTERY	55 lbs
MODEL SIZE	1780 x 620 x 1120 mm
FRAME	Aluminum Alloy
BRAKE	Front & Rear Mechanical Disc 160mm Rotor
BRAKING SYSTEM	Left Brake For Rear/Right Brake For Front
GEARING	7 Speed SHIMANO Derailleur
SHIFTER	7 Speed SHIMANO Derailleur
FORK	Front Suspension
GRIPS	Ergonomic
HANDLEBAR	Aluminum Alloy
SADDLE	Ergonomic Cushion
SENSOR	Speed Sensor
TIRE	20" x 4" CHAOYANG
WEIGHT CAPACITY	200 lbs
RECOMMENDED RIDER	5'3 - 6'3
ACCESSORIES	Kit Box, Kickstand, Reflector, Tool Kit, Fenders

*Ecotric Bicycles Set Speed Limit According To United States Federal Regulations, Maximum Speed In Power Mode Is Programmable And Can Be Adapted To The Local Regulations Of Any Country.
*All Range Estimates Are Contingent Upon Rider And Towing Weight, Wind Speed And Terrain.
